BEP DPDT Rocker Switch - 12V - (ON)/OFF/(ON) [1001713]

DPDT Rocker Switch - 12V - (ON)/OFF/(ON)

Double pole, double throw switch turns two of four circuits on at a time.

Features:

• Nominal voltage is 12V DC
• Rated for 25A at 12V DC
• Six 1/4" blade terminals
• Snap-in mounting to fit panel hole 1.45" x .83" into panels .093" to .187" thick
• Same as Cole Hersee part number 58027-11

*Not rated for use in a 24V system

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Throw/Pole: DPDT
• Color: Black
• Action: (ON)-OFF-(ON)
• Box Dimensions: 2.00"H x 2.75"W x 5.00"L WT: 0.08 lbs
• UPC: 870216046341
